CROSSES S.W.

ANSI B16.11
3000 - 6000 LBS

croc_sw

CROSSES S.W.

ANSI B16.11
3000 - 6000 LBS

Diam. nominale

Nominal pipe size

Dal centro alla base del raccordo A

Center to bottom of socket A

3000

6000

Tolleranze ±

Tolerances ±

mm

inches

mm

inches

mm

inches

1/4"

11.0

0.44

13.5

0.53

1.0

0.03

3/8"

13.5

0.53

15.5

0.62

1.5

0.06

1/2"

15.5

0.62

19.5

0.75

1.5

0.06

3/4"

19.5

0.75

22.5

0.88

1.5

0.06

1"

22.0

0.88

27.0

1.06

2.0

0.08

1 1/4"

27.0

1.06

32.0

1.25

2.0

0.08

1 1/2"

32.0

1.25

38.0

1.50

2.0

0.08

2"

38.0

1.50

41.0

1.62

2.0

0.08

2 1/2"

41.5

1.62



2.5

0.10

3"

57.5

2.25



2.5

0.10

4"

66.5

2.62



2.5

0.10
