tapf_sw

CAPS S.W.

ANSI B16.11
3000 - 6000 LBS

tapf_sw

CAPS S.W.

ANSI B16.11
3000 - 6000 LBS

Diam. nominale

Nominal pipe size

3000

6000

O (1)

P (1)

O (1)

P (1)

mm

inches

mm

inches

mm

inches

mm

inches

1/4"

20

0.59

22

0.87

17.5

0.69

23.1

0.91

3/8"

20

0.67

26

1.02

19.1

0.75

26.7

1.05

1/2"

20

0.75

32

1.26

22

0.87

34

1.34

3/4"

25

0.91

38

1.50

26

1.02

41

1.61

1"

26

1.02

45

1.77

28

1.10

50

1.97

1 1/4"

30

1.10

55

2.17

30

1.18

58

2.28

1 1/2"

31

1.18

60

2.56

32

1.26

66.5

2.62

2"

38

1.42

75

2.95

38

1.50

85

3.35

2 1/2"

41

1.50

95

3.62

42

1.65

100

3.94

3"

43

1.65

110

4.33

45

1.77

120

4.72

4"

48

1.89

140

5.51

51

2.01

150

5.91
(1) Dimensions not listed in ANSI B 16.11-1980 and BS 3799-1974 may vary according to the manufacturer.
