HEXAGONAL NIPPLES

ANSI B16.11
3000 - 6000 LBS

nip

HEXAGONAL NIPPLES

ANSI B16.11
3000 - 6000 LBS

Diam. nominale

Nominal pipe size

A

(mini)

E

(mini)

C

(mini)

W

(mini)

b*

inches

mm

mm

inches

mm

inches

mm

inches

mm

inches

3000

6000

mm

inches

mm

inches

1/8"

6

11

0.43

10

0.39

6

0.24

26

1.02

5

0.20

2

0.08

1/4"

8

15

0.59

15

0.59

6

0.24

36

1.42

8

0.31

6

0.24

3/8"

10

18

0.71

16

0.63

8

0.31

40

1.57

11

0.43

8

0.31

1/2"

15

22

0.87

20

0.79

8

0.31

48

1.89

14

0.55

11

0.43

3/4"

20

27

1.06

21

0.83

10

0.39

52

2.05

19

0.75

13

0.51

1"

25

35

1.38

25

0.98

10

0.39

60

2.36

24

0.94

17

0.67

1 1/2"

40

50

1.97

26

1.02

16

0.63

68

2.68

38

1.50

30

1.18

2"

50

62

2.44

27

1.06

17

0.67

71

2.80

49

1.93

39

1.54

(*) Dimension "b" is nominal and is subject to normal MANUFACTURE tolerances.
Thread according to ANSI B 1.20.1
